Additional information
| material | Forged steel |
|---|---|
| safety-factor | 4 times |
| finish | Painted |
| temperature-range | -40°C up to +200°C, Polar Rated |
| standard-certification | 3.1 material certificate EN 10204, Certificate of Conformity |
ROV Hooks specification
- Material : Forged steel
- Safety factor : 4 times
- Finish : Painted
- Temperature range : -40°C up to +200°C, Polar Rated
- Standard certification : Certificate of Conformity, 3.1 material certificated EN 10204
| WLL ton | MBL ton | A mm | B mm | C mm | D mm | E mm | F mm | G mm | H mm | I mm | P ton | Weight kg |
| 50 | 200 | 103 | 120 | 140 | 125 | 392 | 49 | 73 | 60 | 90 | 2 | 66 |
| 63 | 252 | 109 | 130 | 160 | 140 | 423 | 53 | 85 | 70 | 100 | 3.25 | 90 |
| 80 | 320 | 119 | 140 | 180 | 160 | 265 | 60 | 90 | 80 | 120 | 4.75 | 133 |
| 100 | 400 | 142 | 160 | 190 | 165 | 530 | 65 | 110 | 100 | 140 | 4.75 | 187 |
| 150 | 600 | 157 | 180 | 230 | 200 | 590 | 70 | 120 | 120 | 180 | 6.5 | 314 |
| 200 | 800 | 180 | 210 | 260 | 230 | 678 | 78 | 135 | 145 | 200 | 8.5 | 467 |
| 250 | 1000 | 218 | 250 | 290 | 260 | 750 | 90 | 150 | 170 | 230 | 9.5 | 656 |
| 300 | 1200 | 259 | 300 | 320 | 290 | 865 | 100 | 160 | 180 | 260 | 12 | 915 |
| 400 | 1600 | 280 | 320 | 350 | 320 | 910 | 105 | 180 | 200 | 300 | 17 | 1218 |
| 500 | 2000 | 294 | 340 | 390 | 340 | 985 | 110 | 190 | 220 | 320 | 17 | 1541 |
| 600 | 2400 | 304 | 350 | 420 | 370 | 1035 | 120 | 210 | 250 | 340 | 25 | 1883 |
| 700 | 2800 | 317 | 360 | 450 | 390 | 1060 | 125 | 220 | 280 | 380 | 25 | 2290 |
| 800 | 3200 | 327 | 380 | 500 | 440 | 1180 | 140 | 240 | 300 | 400 | 25 | 2994 |
| 900 | 3600 | 338 | 400 | 520 | 460 | 1260 | 150 | 260 | 320 | 420 | 35 | 3565 |
| 1000 | 4000 | 353 | 420 | 560 | 480 | 1340 | 160 | 280 | 340 | 440 | 35 | 4250 |
| 1250 | 5000 | 371 | 450 | 600 | 530 | 1415 | 185 | 310 | 360 | 480 | 42.5 | 5500 |
| 1550 | 6200 | 394 | 480 | 660 | 590 | 1505 | 205 | 330 | 360 | 540 | 42.5 | 7000 |
