ROV Haken - Softsling vriendelijk - Safe Lifting

ROV Hooks

Category: AB Materiaal Tags: haak, rondtrop, ROV, Softsling, vriendelijk

ROV Haken specificatie

Materiaal : Gesmeed staal
Safety factor : 4x
Afwerking : geverfd
Temperatuur bereik : -40°C tot +200°C, Polar gewaardeerd
Standaard certificatie : Certificate of Conformity, 3.1 material certificated EN 10204

WLL ton	MBL ton	A mm	B mm	C mm	D mm	E mm	F mm	G mm	H mm	I mm	P ton	gewicht kg
50	200	103	120	140	125	392	49	73	60	90	2	66
63	252	109	130	160	140	423	53	85	70	100	3.25	90
80	320	119	140	180	160	265	60	90	80	120	4.75	133
100	400	142	160	190	165	530	65	110	100	140	4.75	187
150	600	157	180	230	200	590	70	120	120	180	6.5	314
200	800	180	210	260	230	678	78	135	145	200	8.5	467
250	1000	218	250	290	260	750	90	150	170	230	9.5	656
300	1200	259	300	320	290	865	100	160	180	260	12	915
400	1600	280	320	350	320	910	105	180	200	300	17	1218
500	2000	294	340	390	340	985	110	190	220	320	17	1541
600	2400	304	350	420	370	1035	120	210	250	340	25	1883
700	2800	317	360	450	390	1060	125	220	280	380	25	2290
800	3200	327	380	500	440	1180	140	240	300	400	25	2994
900	3600	338	400	520	460	1260	150	260	320	420	35	3565
1000	4000	353	420	560	480	1340	160	280	340	440	35	4250
1250	5000	371	450	600	530	1415	185	310	360	480	42.5	5500
1550	6200	394	480	660	590	1505	205	330	360	540	42.5	7000

Additional information

Additional information

material	Forged steel
safety-factor	4 times
finish	Painted
temperature-range	-40°C up to +200°C, Polar Rated
standard-certification	3.1 material certificate EN 10204, Certificate of Conformity
